View Issue Details [ Jump to Notes ]

[ Issue History ] [ Print ]

ID

Project

Category

View Status

Date Submitted

Last Update

0000013

easycwmp

[All Projects] Help

public

2014-09-26 21:46

2014-09-30 09:58

Reporter

CwmpUser

Assigned To

Anis

Priority

normal

Severity

minor

Reproducibility

always

Status

resolved

Resolution

fixed

Platform

openwrt

OS

OS Version

Summary

0000013: Cannot get IP address

Description

I use get value command to get "InternetGatewayDevice.WANDevice.1.WANConnectionDevice.1.WANIPConnection.1.ExternalIPAddress", which turns out to be empty, also I can't see AP'IP on server. Is this suppose to be like this? Thanks in advance!

Tags

No tags attached.

2014-09-26 15.44.30.jpg [^] (4,319,595 bytes) 2014-09-26 21:46

2014-09-26 15.44.48.jpg [^] (2,701,850 bytes) 2014-09-26 21:47

Relationships

Notes
(0000056) mohamed.kallel (manager) 2014-09-29 10:28 edited on: 2014-09-29 10:29	You have to update the wan_device script. The wan_device script is under the "ext/openwrt/scripts/functions/" in the source code. And its under "/usr/share/easycwmp/functions" in your openwrt firmware. In the wan_device script, you have to change the function: "get_wan_device_mng_interface_ip()". you have to change the line: "network_get_ipaddr val mng". Change the "mng" by the name of you wan interface. The same thing for the "InternetGatewayDevice.WANDevice.1.WANConnectionDevice.1.WANIPConnection.1.MACAddress", you have to change the function "get_wan_device_mng_interface_mac()". you have to change the "val=`$UCI_GET network.mng.macaddr`" by "val=`$UCI_GET network.<your_wan_interface>.macaddr`"

Issue History
Date Modified	Username	Field	Change
2014-09-26 21:46	CwmpUser	New Issue
2014-09-26 21:46	CwmpUser	File Added: 2014-09-26 15.44.30.jpg
2014-09-26 21:47	CwmpUser	File Added: 2014-09-26 15.44.48.jpg
2014-09-29 10:28	mohamed.kallel	Note Added: 0000056
2014-09-29 10:29	mohamed.kallel	Note Edited: 0000056	View Revisions
2014-09-29 20:37	CwmpUser	Note Added: 0000057
2014-09-29 20:39	CwmpUser	Note Deleted: 0000057
2014-09-29 20:48	CwmpUser	Note Added: 0000058
2014-09-29 21:13	CwmpUser	Note Deleted: 0000058
2014-09-30 09:58	Anis	Status	new => resolved
2014-09-30 09:58	Anis	Resolution	open => fixed
2014-09-30 09:58	Anis	Assigned To	=> Anis
